The typical potentiometer will have 3 pins, two power supply pins (+5V and GND), and one pin that connects to an analog input pin on your Arduino to read the value output. To learn how to read data from a potentiometer, and display it in the Serial Monitor, visit the Analog Read Serial example. Hardware Required. Arduino board; Potentiometer Arduino - Rotary Potentiometer. Arduino's pin A0 to A5 can work as analog input. The analog input pin converts the voltage (between 0v and VCC) into integer values (between 0 and 1023), called ADC value or analog value.. By connecting an output pin of the potentiometer to an analog input pin, we can read the analog value from the pin, and then converts it to a meaningful value.

Step 4: Connect the Transistor,diode,resistor and the D.C.motor. 1) Connect the BASE of the transistor to a 220ohms resitor and connect the end of the resistor to DIGITALPIN3 on the arduino. 2) Connect the COLLECTOR of the transistor to a negative of a diode and connect the end of the diode to GND. 3) Connect the EMITTER of the transistor to. The project consists ATMEGA328 microcontroller, IR sensor, L293D motor driver, ALPS Motorized potentiometer, a connector for Arduino programming, etc. The L293D H-bridge drives the potentiometer motor, 2 Parallel direction pins are used to change the motor direction which moves the POT in a forward or reverse direction.
